DustHog VP-750 Portable Cartridge Dust Collector, 750 CFM

Description

Roll it to the job. Self cleaning cartridge filtration on casters, for the shop where the work is never twice in the same place.

You are buying this for portable source capture on welding, grinding and cutting that moves.

We are an authorized DustHog distributor and we sell this line every week. That means you get the right part number the first time rather than a catalog page and a phone number.

Choose your capture

This unit takes DustHog’s XA source capture swing arm, 6 in. diameter in 7, 10 or 12 ft, or a 6 in. inlet collar in place of the arm if you are running your own hose. Pick yours from the Arm dropdown above and it ships on the same truck as the machine.

Configure it

Pick your build from the Configuration dropdown above. Every entry is a real factory part number, with horsepower, voltage and filter options already resolved, with the part number shown in brackets so you can check it against a drawing or a previous order. 4 configurations available on this model.

What you get

• A genuine DustHog unit, built to order at the factory
• Ships LTL freight. We quote the actual freight and confirm it with you before anything leaves the factory, so there is no surprise on the invoice
• The part number confirmed with the factory before we place it
• Replacement filters and spare parts listed on this site so you are not hunting them in two years

Downloads

• DustHog V-Series owner’s manual, models VB, VF and VP (PDF)

Who this is not for

• Explosive dust or an explosive atmosphere. Parker’s V Series owner’s manual says do not use this unit in explosive atmospheres and do not collect emissions that are explosive. If your dust is combustible, call us before you order.
• Air that has to leave the building. The manual describes the V Series returning the cleaned air to your work area. If your process or permit requires exhausting outside, sort that out before you choose this unit.
• Pulse cleaning without shop air. The pulse cleaning configurations need a clean, dry 90 to 110 PSIG compressed air supply, per the manual. The manual also lists an option where you clean the filters by hand outside the cabinet. Ask us which configuration that is.
• Sparks with no spark protection. For metal grinding and other spark producing processes, the manual says care must be taken to reduce fire hazards. Plan for that before sparks can reach the cartridges.

Not sure which configuration fits your machine or your room? Get a free assessment and we will spec it with you before you spend a dollar.

Part numbers for this unit

Every configuration of this unit lives on this page. If you came in with a part number from a quote, a drawing, or an old nameplate, match it against the list below, then pick that configuration above.

VP-0750, VP-0750-C11XFN, VP-0750-C11XNN, VP-0750-C12XFN, VP-0750-C12XNN, VP-0750C11XFN, VP-0750C11XNN, VP-0750C12XFN, VP-0750C12XNN

Parts that fit this collector

Matched to the DustHog V-Series from the factory parts list. Click any part to go straight to it.

Filters and cells

• Carbon After Filter (33-1219)
• ProTura® Nanofiber (33-10097)
• ProTura® Nanofiber (33-10098)
• ProTura® Nanofiber Fire Retardant (FR) (33-10097-1)
• ProTura® Nanofiber Fire Retardant (FR) (33-10098-1)
• ProTura® Nanofiber Fire Retardant (FR) Wide Pleat (33-10097-15)
• ProTura® Nanofiber Fire Retardant (FR) Wide Pleat (33-10098-15)
• ProTura® Nanofiber Wide Pleat (33-10097-5)
• ProTura® Nanofiber Wide Pleat (33-10098-5)

Electrical

• Pulse Control Board, V-series (20-3232)
• Valve, Diaphragm, 1 in. Comp., DP25 (07-10002-0002)

Mounting and hardware

• Caster Rigid, 5 in. Dia. (17-0026)
• Caster-Swivel, 5 in. DIA.W/Lock (17-0027)

Hoses and ducting

• Steel Tube V-series (39-0268)

Ducting and connections

Match to the inlet collar size you configured on this unit.

6 in.

• 6 in. Clamps, EA (15-0004)
• 6 in. Flexhose, Per Foot (15-0107)
• 6 in. Inlet Collar, Flange (3261-0600)
• 6 in. Inlet Collar, Slip (03-10812)
• Elbow Brkt, Left, 6 in. SA, Insid (10-12688-1M)
• Elbow Brkt, Left, 6 in. SA, Outsi (10-12689-2M)
• Elbow Brkt, Right, 6 in. SA, Insi (10-12689-1M)
• Elbow Brkt, Right, 6 in. SA, Outs (10-12688-2M)

8 in.

• 8 in. Clamps, EA (15-0005)
• 8 in. Flexhose, Per Foot (15-0071)
• 8 in. Inlet Collar, Flange (3261-0800)
• 8 in. Inlet Collar, Slip (03-10813)
• Cap 8 in. Uncrimped (15-0024)
• Elbow Brkt, Left, 8 in. SA, Insid (10-12688-3M)
• Elbow Brkt, Left, 8 in. SA, Outsi (10-12689-4M)
• Elbow Brkt, Right, 8 in. SA, Insi (10-12689-3M)
• Elbow Brkt, Right, 8 in. SA, Outs (10-12688-4M)
• Flex DUCT-8 in. (15-0049)

Swing arms for this unit

DustHog lists 7, 10 and 12 ft. industrial swing arms as options on the VP.

• XA Swing Arm, 6 in. Dia, 10′ Long, Portable (01-10161)
• XA Swing Arm, 6 in. Dia, 10′ Long, Wall (requires Kit 03-10615-U) (01-10164)
• XA Swing Arm, 6 in. Dia, 12′ Long, Portable (01-10162)
• XA Swing Arm, 6 in. Dia, 12′ Long, Wall (requires Kit 03-10615-U) (01-10165)
• XA Swing Arm, 6 in. Dia, 7′ Long, Portable (01-10160)
• XA Swing Arm, 6 in. Dia, 7′ Long, Wall (requires Kit 03-10615-U) (01-10163)
• XA Swing Arm, 8 in. Dia, 10′ Long, Portable (01-10148)
• XA Swing Arm, 8 in. Dia, 10′ Long, Wall (requires Kit 03-10611-U) (01-10151)
• XA Swing Arm, 8 in. Dia, 12′ Long, Portable (01-10149)
• XA Swing Arm, 8 in. Dia, 12′ Long, Wall (requires Kit 03-10611-U) (01-10152)
• XA Swing Arm, 8 in. Dia, 7′ Long, Portable (01-10147)
• XA Swing Arm, 8 in. Dia, 7′ Long, Wall (requires Kit 03-10611-U) (01-10150)
